BEXCP3ABG EXPROOF BREAK GLASS CALL POINT (GYAE2SBEXCP3ABG)

BEXCP3ABG EXPROOF BREAK  GLASS CALL POINT

Options
Alternative housing colours are available to meet specific requirements.
DIN rail mounted terminal blocks: 8 × 2.5mm²
Stainless Steel lift flap
Metalised Polyester “Duty” label.
Series and/or End of Line resistors.

Approvals
ATEX certificate: Sira 09ATEX3286X
IECEx certificate: IECEx SIR 09.0121X
INMETRO certificate: 10-IEx-0011X
Ex EAC TR CU 012/2011 certified: KZ.1510019.22.01.00271
SIL 2 certified to IEC 61508 (2010)
Complies with design requirements of EN54-11

Specification
BExCP3A-BG:  II 2G Ex d e IIC T6 Gb
                         II 2D Ex t IIIC T60°C Db
                         IP66

Ambient: Ta = -40°C to +55°C [-40° to +131°F]
