The Optical smoke detector OC05Ex analyzes an atmosphere by reflection of a light on the particles of smoke according to TYNDALL effect.
It detects especially the cold and visible smoke particles (0,3µm to 2µm) produced in the early stages of a fire. The threshold of response of alarm is regulated to obtain the value m=0, 180db/m ± 0, 03 according to standard EN54-7. OC05Ex includes a developed technology (microprocessors, smd components) which means precision and high reliability.
OC05Ex is a conventional Atex detector and it can work in a intrisically safe area.
Main characteristics
Photoelectric scattering (Tyndall effect)
1 remote alarm indicator output
Lockable
Standard EN54-7
Cable section max 2,5mm² Atex certified
Atex certified
Power supply specification
Main supply voltage
10Vdc to 28 Vdc
Nominal main supply voltage
20 Vdc
Quiescent current (20 Vdc)
<150µA
Alarm current (20 Vdc) with BSI 280Ω
24mA ± 2mA
Auxiliary output
When fire alarm
On
Mechanical characteristics
Unit weight
130g
Unit dimensions (in mm)
H:55 D:104
Unit row material
ABS Atex
Unit colour
White
IP rating
IP32
Mounting mode
Base
Fixing
- distance between centres: 50mm to 60mm - under ceiling: 2 screws Ø 4
Climatic characteristics
Operating temperature
-20°C to + 55°C
Storage temperature
+10°C to + 50°C
Operating relative humidity
≤ 93% HR
